Graphics card Sapphire AMD Radeon 9060 XT PULSE OC [11350-03-20G]

#5631364

Graphics card Sapphire AMD Radeon 9060 XT PULSE OC [11350-03-20G]

[PCIe 5.0, 16 GB GDDR6, 128 bit, 2 x HDMI, DisplayPort] details

4.92 | 209

Not on sale

Warranty: 12 mos.

Accessories

  • Characteristics
  • Feedback 209

Characteristics Graphics card Sapphire AMD Radeon 9060 XT PULSE OC [11350-03-20G]

Factory specifications

Manufacture country
Taiwan (Province Of China)

General parameters

Type
graphics card
Model
Sapphire AMD Radeon 9060 XT PULSE OC
Manufacturer Code
[11350-03-20G]
Color
black
Designed for Mining (Cryptocurrency Mining)
none
LHR
none

Basic parameters

Graphics Processor
Radeon RX 9060 XT
Microarchitecture
AMD RDNA 4
Technical Process
5 nm

Video processor specifications

Turbo Frequency
3290 MHz
Number of Universal Processors (ALU)
2048
Texture Blocks
128
Number of Raster Operations Units
64
Ray Tracing Support
yes
Ray Tracing Hardware Acceleration (RT Cores)
32
Tensor Cores
0

Video memory specifications

Video Memory Size
16 GB
Memory Type
GDDR6
Memory Bus Bit Depth
128 bit
Max Memory Bandwidth
320 GB/s
Effective Memory Frequency
20000 MHz

Image Output

Type and Number of Video Interfaces
DisplayPort, 2 x HDMI
DisplayPort Version
2.1a
Multi-Monitor Setup
3
Max Resolution
7680x4320 (8K Ultra HD)

Connection

Connection Type
PCIe 5.0
Connector Form Factor
PCIe x16
Number of PCI Express Lanes
16
Extra Power Connectors
8 pin
Recommended Power Supply
450 W
Power Consumption
170 W

Cooling System

Cooling Type
active air
Type and Number of Installed Fans
2 axial
Liquid Cooling Radiator
none

Additional Information

GPU RGB Lighting
none
RGB Lighting Sync
none
LCD Screen
none
Dual BIOS Switch
none
Features, Additional
metal backplate, Infinity Cache - 32 Mb
Package Contents
documentation

Dimensions and Weight

Low Profile Card
none
Number of Occupied Expansion Slots
2.3
GPU Length
240 mm
Graphics Card Width
124 mm
GPU Depth
46.1 mm

Description

Видеокарта Sapphire AMD Radeon 9060 XT PULSE OC [11350-03-20G] рассчитана на комплектацию игровых ПК. Устройство оснащено графическим процессором Radeon RX 9060 XT и 16 ГБ памяти GDDR6. Допускается одновременное подключение 2 или 3 мониторов. Видеоадаптер поддерживает разрешение до 7680x4320 (8K Ultra HD).
