Access point MikroTik cAP ac

#1239552

Access point MikroTik cAP ac

[ports: 2 pcs, 100 Mbit/s, 1000 Mbit/s, Wi-Fi 802.11 5 GHz, 2.4 GHz, 1167 Mbit/s] details

Not on sale

  • Characteristics
  • Feedback 301
  • Instructions and files

Characteristics Access point MikroTik cAP ac

General parameters

Type
access point
Model
MikroTik cAP ac
Manufacturer Code
[RbcAPGi-5acD2nD]
Main Color
white

Design

Placement
indoor
Installation
wall-mounted
Compact Design
none

Wi-Fi Parameters

Wi-Fi Standard
5 (802.11ac), 4 (802.11n)
Wi-Fi Class
AC1200
Transmitter Operating Frequency
5 GHz, 2.4 GHz
Max Wireless Speed
1167 Mbit/s
Max Speed at 2.4 GHz
300 Mbit/s
Max Speed at 5 GHz
867 Mbit/s
Dual Band Operation
yes
Transmitter Power Output
20 dBm
Operating Modes
guest network, repeater, router, access point
Wireless Connection Security
WEP, WPA2, WPA2-Enterprise, WPA2-PSK, SSID Broadcast Disabling

Antenna

Type of Antenna
internal
Removable Antenna
none
Antenna Count
4
Antenna Gain
2.5 dBi

Ports

Connectors/Ports
Ethernet, Wi-Fi
LAN Port Count
2 pcs
Ethernet Data Transfer Rate
100 Mbit/s, 1000 Mbit/s
USB Ports
none

Functionality

Controls
WinBox program, SSH, Telnet, mobile app, web interface, SNMP
Support For Mesh
none
DHCP
yes
Multi-Stream Data Transfer
MIMO 2x2
Support For WiMAX
none
Advanced Features
power adjustment, NAT, wi-fi statistics, VLAN, port forwarding
Additional Connection Protection
MAC filtering, IP20, IP filtering

Power

Support For PoE
IEEE 802.3af (PoE), IEEE 802.3at (PoE+)
Passive PoE
yes
Input Voltage
PoE 17-57V
Output Voltage
Passive PoE 57V
Built-In Socket
none

Operating Conditions

Operating Temperature Range
-40℃ ~ +50℃
Humidity Level
10% - 90% without condensation

Additional Information

Mobile App
MikroTik
Buttons
mode selection, factory reset
Features
RouterOS: Level4 version
Package Contents
power supply, power cable, documentation, installation kit, PoE injector, housings x2 pcs (round/square)

Dimensions and Weight

Width
145 mm
Length
145 mm
Height
30 mm
Weight
400 g

Dimensions and Weight in Packaging

Package Width
267 mm
Package Height
61 mm
Packaging Depth
187 mm
Packaged Weight
767 g

Description

The Mikrotik RbcAPGi-5acD2nD access point is intended for indoor use. The model is manufactured by a widely known maker of professional-grade telecommunications equipment. The access point supports the 2.4 and 5 GHz bands. Broadcasting is performed simultaneously in both bands. The maximum wireless connection speed is 867 Mbps. Supported operating modes include access point, guest network, WISP router, and repeater.
The Mikrotik RbcAPGi-5acD2nD access point is equipped with 2 Gigabit Ethernet ports with PoE support. The device is designed for wall mounting. A special feature of the access point's package is the inclusion of two enclosures: round and square. The package also includes a power supply, a mounting kit, and a PoE adapter. The operating temperature of the model ranges from 0 to 40 °C. The maximum permissible relative humidity is 95%. The weight of the access point is 400 g. The model is packaged in a sturdy cardboard box.
