VDSL/ADSL router TP-LINK TD-W9960

#1348702

VDSL/ADSL router TP-LINK TD-W9960

[4x10/100 Mb/s, ADSL, ADSL2, ADSL2+, VDSL2, 100 Mbit/s, Wi-Fi 802.11 2.4 GHz, 300 Mbit/s, IPv6] details

140 000 UZS
Buy
Avail in 2 shops
  • Characteristics
  • Feedback 42
  • Instructions and files

Characteristics VDSL/ADSL router TP-LINK TD-W9960

General parameters

Type
VDSL/ADSL router
Model
TP-LINK TD-W9960
Main Color
blue, white

Internet network connection types (WAN)

WiFi Connectivity
none
Support For IPv6
yes

Built-in ADSL Modem Parameters

ADSL Generation
ADSL2+, VDSL2, ADSL, ADSL2
Supported ADSL Standards
none
Max Inflow Rate
100 Mbit/s

Wi-Fi

Wi-Fi
yes
Wi-Fi Standard
4 (802.11n)
Wi-Fi Transmitter Frequency
2.4 GHz
Wi-Fi Class
N300
Max Wi-Fi Speed
300 Mbit/s
Dual Band Operation
none
Type and Number of Antennas
external x2
Connection Security
WPA-PSK, WEP, WPA, WPA2, WPA2-PSK

Ports

Port Count
3x LAN, 1x LAN/WAN, 1x DSL
Переназначение WAN/LAN портов
manual
WAN
yes
Number of LAN Ports
4
Base Data Transfer Rate
10/100 Mb/s
USB Port Count & Gen.
none

Routing

Support For DHCP
yes
NAT
yes
Network Protocols
UPnP, VLAN

Safety

Firewall
yes
Extra Safety Functions
MAC filtering, SPI, parental control, DMZ, IP filtering, DDoS protection

Functions and Technologies

Controls
mobile app, web interface, TR-069
Secure Connection Features
VPN pass through
Supported Technology
QoS
IP Multicast
IGMP v3, IGMP v2, IGMP v1

Additional Information

Can Be Installed Outdoors
none
Power Type and Voltage
DC 9V/0.6А
Device Buttons
factory reset, WPS, power on
Display
DSL, power, internet, Wi-Fi, LAN
Package Contents
power supply, documentation, splitter, RJ-11 cable, Ethernet RJ-45 cable
Additional Information
guest network, surge protection
Operating Temperature
from 0°C to 40°C

Dimensions and Weight

Width
181.6 mm
Depth
129.7 mm
Height
36.2 mm

Description

The TP-LINK TD-W9960 ADSL2+ router features an eye-catching design that will certainly attract attention. However, the router's primary purpose is providing internet access via DSL line resources. Support for the VDSL2 standard allows the device to ensure downstream speeds of up to 100 Mbps. The same speed is provided by the WAN port, which is shared with one of the four LAN ports.
The TP-LINK TD-W9960 ADSL2+ router supports 802.11b, 802.11g, and 802.11n standards. Wireless broadcasting is handled by two external antennas operating in the 2.4 GHz band. The router offers extended range capability, providing a strong wireless signal across large apartments or houses with substantial square footage.
The allowable operating temperature range for the router is 0 to 40 °C. The device is intended for indoor use. The package includes a power adapter, documentation, an Ethernet cable, and a telephone cable. Model dimensions are 181.6x129.7x36.2 mm.
